The FX+ 2 is a lightweight city electric bike that’s designed to make everyday excursions faster and more fun. It has an intuitive and natural feeling pedal-assist system that makes exploring your city extra exciting and cruising up hills a breeze. Useful accessories like a rack and mudguards add even more versatility to this bike.
It's right for you if...
You want a lightweight, simple-to-use city e-bike that brings a capable boost to daily errands, commutes and joy rides around your city.
The tech you get
A lightweight aluminium frame and fork, Trek's proprietary pedal-assist system with a hub motor (250 W, 40 Nm) that assists up to 20 mph (25 km/h in Europe) and a 250 Wh battery for a range of up to 56 kilometres per charge. Plus, fast 700c wheels, fast-rolling yet stable 40c tyres with reflective sidewalls, a reliable 9-speed Shimano drivetrain, hydraulic disc brakes, integrated lights powered by the battery, a MIK-compatible rear rack, mudguards and a kickstand.
The final word
All the versatility and confidence of FX, with an electric boost that helps you do more and go further! The FX+ also comes with ride-ready accessories like a rack and mudguards that make it easier to commute and run errands.
Specifications
*spec applies to all sizes unless otherwise noted
| Frame | Alpha Gold Aluminium, internal cable routing, internal battery, rack and mudguard mounts, flat-mount disc, kickstand mount, 144.5 mm OLD hub motor spacing |
|---|---|
| Fork | FX+ alloy, internal brake routing, mudguard mounts, rack mounts, ThruSkew 5 mm bolt-on skewer |
Wheels
| Hub front | Formula DC-20, alloy, 6-bolt, 5x100 mm QR |
|---|---|
| Skewer front | 132x5 mm QR |
| Hub rear | Hyena hub drive motor, 40 Nm, 250 W |
| Rim | Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve |
| Spokes | 14 g stainless steel, black |
| Tyre | Bontrager H2 Comp, reflective strip, wire bead, 30tpi, 700x40c |
| Max tyre size | 700x50mm without mudguards, 700x45mm with mudguards |
Drivetrain
| Shifter | Shimano Altus M2010, 9-speed |
|---|---|
| Rear derailleur | Shimano Altus M2000, long cage |
| *Crank |
Size: S, M ProWheel Pro alloy, 42T narrow-wide steel ring, 170 mm length |
|
Size: L, XL ProWheel Pro alloy, 42T narrow-wide steel ring, 175 mm length |
|
| Bottom bracket | Torque sensor, threaded, 122.5 mm spindle |
| Cassette | Shimano HG200, 11-36, 9 speed |
| Chain | KMC E9S, 9-speed |
| Pedal | slip-proof pedals with reflectors |
| Max. chainring size | 1x: 42T |
Components
| Saddle | Bontrager Sport |
|---|---|
| *Seatpost |
Size: S, M Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length |
|
Size: L, XL Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length |
|
| *Handlebar |
Size: S, M Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width |
|
Size: L, XL Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width |
|
| Grips | Bontrager XR Endurance Comp, lock-on |
| *Stem |
Size: S, M Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length |
|
Size: L, XL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length |
|
| Brake Set | Promax DSK-927 hydraulic disc, flat mount, 160 mm rotor |
| Rotor size | Max brake rotor sizes: 160mm front & rear |
Accessories
| Battery | 250 Wh, integrated in down tube, Range Extender compatible |
|---|---|
| Charger | 2A, 42V output, 100V–240V AC input |
| *Light |
Size: S, M, L, XL Herrmans MR4, 120-lumen LED |
|
Size: S, M, L, XL Spanninga Solo |
|
| Computer | LED display |
| Kickstand | Pletscher Comp 18 |
| Cargo rack | MIK-compatible alloy rear rack, maximum load 25 kg |
| Mudguard | SKS plastic |
Weight
| Weight | M - 17.69 kg / 38.99 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
